XCMG brand 37m Boom-type concrete pump truck Concrete Boom Cement Pump Truck 37.4M Reach Height

Name: XCMG brand 37m Boomtype concrete pump truck Concrete Boom Cement Pump Truck 374M Reach Height
Brand: CIVL
Price: 1 USD

Brand Name : CIVL

Model Number : CIVL

Certification : ISO,CCC

Place of Origin : China

MOQ : 1

Price : Negociable

Payment Terms : L/C, T/T

Supply Ability : 20 set / month

Delivery Time : Within 35 days

Packaging Details : nude

Reach height : 37.4M

Reach depth : 23.7M

Theoretical output : 138/90m3/h

Condition : New

Warranty : 12 months

Total weight : 28150kg

made year : 2021

Contact Now

No.	Item	Unit	Parameter
1	Max. speed	km	90
2	Min. turning diameter	m	18.4
3	Brake distance	m	7
4	Approach angle	°	31
5	Departure angle	°	12
6	Chassis model		SINOTRUK HOWO
7	Total weight	kg	28150
8	1st axle load	kg	6780
9	2nd, 3rd axle load	kg	21220
10	Engine model		WD615
11	Max. Engine power	kW	287
12	Max. Engine torque	N.m	1862
13	Max. grade-ability	%	38
14	Fuel consumption limit	L/100km	34
15	Outline dimensions (Length´ Width ´Height)	mm	11990´2490´3900

Technical Data for Pumping Operation

No.	Item	Unit	Parameter
1	Theoretical output	m3/h	138/90
2	Max. delivery pressure	MPa	8.7/13
3	Reach height	m	37.4
4	Reach depth	m	23.7
5	Front outrigger transverse span	mm	7280
6	Rear outrigger transverse span	mm	6600
7	Outrigger longitudinal span	mm	6860
8	Delivery pipe diameter	mm	125
9	Remote control distance	m	100
10	Placing boom slewing range	°	370

XCMG brand 37m Boom-type concrete pump truck Concrete Boom Cement Pump Truck 37.4M Reach Height

The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY.
Truck series:

1.dump trucks; cargo trucks
2. tractor trucks;
3. tanker trucks,( water tanker and oil tanker)
4. mixer trucks and concrete pump truck
5. mine dump trucks( 4x2 off-road mine tipper, 6x4 70T mine dump truck, 6x6 articualted dump trucks)
6. full drive trucks( 4x4. 6x6 and 8x8 Trucks)
7, garbage trucks( garbage compector truck, suction trucks)
8. truck cranes(normal road truck crane, truck mounted crane)
9. special trucks( wrecker trucks, military trucks...)
10. truck trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11. truck spare parts( howo, howo A7, golden prince all series trucks parts supplying)

Machine series:

1.Wheel loader,Backhoe loder, brick making machine

2.Roller,

3.Motor Grader,

4.Bulldozer,

5.Excavator,

6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane),

7,forklift and 45t contain reach stacker

8,paver and so on
