Popular sale Chinese brand new sinotruck dump truck howo 6x4 18m3

SINO VEHICLE & EQUIPMENT COMPANY LTD
Contact Now

Popular sale Chinese brand new sinotruck dump truck howo 6x4 18m3

Brand Name : CIVL

Model Number : CIVL

Certification : ISO,CCC

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T

Supply Ability : 1000 sets per month

Delivery Time : Within 35 days

Packaging Details : In nude

Drive Wheel : 6x4

Horsepower : 351 - 450hp

Transmission Type : Manual

Fuel Type : Diesel

Transmission : HW19710 ,10 forward and 2 reverse

Contact Now

Hot sale Chinese brand new sinotruck dump truck howo 6x4 18m3

Product Description

Popular sale Chinese brand new sinotruck dump truck howo 6x4 18m3

Main Parameter
SINOTRUK HOWO 336HP 6x4 dump truck/tipper truck
Truck Model ZZ3257N3447A
Cargo Body Size (LxWxH) 5200x2300x1300 mm
Lifting Type Ventral Lifting
Overall dimensions (LxWxH) 7835*2496*3170 mm
Approach angle/Departure angle(°) 19/27
front/rear suspension (mm) 1500/1560
Axle base (mm) 3425+1350
Max speed(km/h) 75
Vehicle Curb weight(kg) 12380
Gross mass (kg) 25000
Engine Model SINOTRUK WD615.69,
4-stroke direct injection diesel engine,
6-cylinder in-line with water cooling,
turbo-charging and intercooling
Power, max(kw/rpm) 336 HP
Emission Euro2
Transmission/Gear box Model HW19710, 10 speeds forward ,2 reverse
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Auxiliary brake Engine exhaust brake
Steering system Model 8118,hydraulic steering with power assistance
Front axle HF 9,drum
Driving axle HC16,double reduction
Tire 12.00R20,radial tyres; optiong:12.00-20
Clutch φ430 diaphragm spring clutch,hydraulic control air
power assisted
Cab HW70, with A/C
VOLVO technology ,comfortable cab.
4-point support floating suspension and shock absorbers,
up/down and front/back adjustable steering wheel,
VDO instrument and control module,safety belt ,
air horn,outer sun visor.
Electric system Battery 2x12V/165Ah
Alternator 28V-1500 KW
Starter 7.5 Kw/24 V
Color red,white,yellow. Optional as per customer’s requests.
Packaging & Shipping

Popular sale Chinese brand new sinotruck dump truck howo 6x4 18m3

We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.

We have received more than 1000 clients and training engineers from more than 100 countries around the world.

Our Services

we are famous professional construction machinery exporter and one stop solution supplier in China, our team have more than 10 years experience in this field already.

(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.

(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.

(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.

(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.

(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.
