Specifications
(1) 4x2 garbage truck
(2) Hyva Hydraulic system
(3) Euro II emission.
(4) Horse Power 266HP
(5) Displacement: 9.726L
(6) Dump Box Volume: 18 cbm
(7) Certification: ISO9001 CCC,SGS
Technical Parameters
| Cabin | Driving type 4x2 LHD/RHD
Model: ZZ325 |
| HW70 standard cab,no bunk,safety belts,left hand driving,air conditioner. |
| Carriage Dimensions | 5800x2200x1400 mm |
| Wheel Base | 3800+1350 mm |
| GVW | 25000kg |
| Front axle loading capacity | 1 x 9000 |
| Rear axles loading capacity | 1 x 16000 |
| Engine | Brand | Sinotruk |
| Model | WD615.62 |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Displacement | 9.726L |
| Bore x Stroke | 126x130mm |
| Horse Power (HP) | 266 |
| Emission standard | Euro II |
| Max Speed | 75 km/h |
| Tire | 12.00-20, 12.00R20, 295/80R22.5, 12R22.5, 315/80R22.5 |
| Transmission | HW15710 or HW19710 transmission ,10 forward and 2 reverse |
| Steering | ZF8098 |
| Oil Tank | 300L Aluminum alloy fuel tank |
| Carriage Internal Dimensions | 5800x2200x1400 mm |
| Cubage | 18 cbm |
| Lift of Carriage | Hyva System |
| Brake System | Service brake:dual circuit compressed air brake |
| Parking brake (emergency brake):spring energy,compressed air operating on rear wheels |
| Auxiliary brake:engine exhaust valve brake |
| Electrics | Operating voltage:24V,negative grounded |
| Batteries:2x12 V,165 Ah |
| horn,headlamps,fog lights,brake lights,indicators and reverse light |
| Option | Vertical Muffler;ABS;Automatic Break Clearance Adjusting Arm;Traveling Data Recorder; Metal Pipeline;Engine Protective Board |
Description:
Carriage Removable Garbage Collection Truck, the full introduction of the German production of technology and design. Using CNHTC truck chassis, the hydraulic system, electrical and electronic control system, lubrication system and the main parts are domestic and imported famous brand. Good in appearance and performance. This type of garbage truck is mainly used for municipal solid waste (MSW), commercial waste, and are used for non-toxic, non corrosive and non industrial radioactive waste collection and transportation.
Can realize a main vehicle equipped with a plurality of garbage box, reduce the total cost of operation. Rapid completion of loading and unloading and automatic garbage compression cycle control. Use of lightweight container design, greatly reducing the weight of the vehicle itself. Vehicle bridge load-bearing by heavy truck 16 tons of bridge, a large tonnage, improves the carrying capacity. At the same time with compression of the cargo, by of garbage filling and compression, reduce the volume of garbage, so as to further enhance the rate of volume, improve work efficiency.
Container with guide roller, the HYVA18 tons pull arm, hydraulic system, ensure convenient to load and unload the garbage box, improve work efficiency. Standard after the roller support or rear axle support and improve the stability of vehicle in the soft road for loading and unloading;
The hydraulic system adopts the integrated design, which reduces the number of parts of the system, and improves the reliability of the system.
Applications:
Which is mainly used for municipal solid waste (MSW), commercial waste, and are used for non-toxic,
non corrosive and non industrial radioactive waste collection and transportation.
Competitive Advantage:
1) The vehicle function is complete, easy to operate, big garbage loading capacity
2) the hydraulic drive and electronic program controller control is more accurate and with reliable performance
3) The optimized hydraulic control system helps to avoid wrong operation, it has higher safety and running
efficiency.
4) excellent appearance of cabin, safety, reliable
5) low fuel consumption
6) with all kinds of truck model, which can fulfill your requirement
7) the key parts adopt the world's top technology products
8) based on strong technical support and top level technology make the trucks with high quality and more
reliable
9) competitive price, cost-effective
10) quick and efficient spare parts supply bring you more convenient
11) fast delivery time, we can arrange production according to your needs exactly and quickly
12) professional import and export dealing procedure, make customs clearance more high efficiency
