Brand Name : XCMG
Model Number : CVXE250C
Certification : ISO,CE
Place of Origin : China
MOQ : 1set
Payment Terms : L/C, T/T
Supply Ability : 100Unit/Units per Year
Delivery Time : 35 work days
Packaging Details : In nude
Brand : XCMG
Model : CVXE250C
Condition : New
Operating Weight : 25000kg
Bucket capacity : 1.0 M³
Travel speed : 5.5/3.7/Km/h
XCMG official manufacturer CVXE250C used excavator price.
Excavators are widely used in construction, road construction, water conservancy, electric power, mining, petroleum, natural gas pipeline laying and military engineering . Main operation object : excavator is mainly used for roadbed excavation and foundation excavation in construction, digging ditches, canals and dredging rivers in water conservancy projects, stripping and mining of ore in quarries, open-pit mining and other projects. According to statistics, more than 60 % of the earth and stone in the construction work is done by excavators. Other purposes : after the excavator changes the working device, it can also be broken, removed, cast, lifted, installed, and piling, rammed earth and plucked piles.
SPECIFICATION
Unit | Parameters | ||
Model | Operating Weight | Kg | 25000 |
Bucket capacity | M³ | 1.0 | |
Engine | Engine model | / | |
Direct injection | / | √ | |
4x strokes | / | √ | |
Water cooling | / | √ | |
Cylinders | / | ||
Output power of engine | Kw/rpm | 142/2000 | |
Mar torque/speed | N.m/rpm | 803/1500 | |
Displacement | L | 6.7 | |
Main performance | Travel speed | Km/h | 5.5/3.7 |
Siewing speed | r/min | 10.9 | |
Gradient capability | ° | ||
Ground pressure | kPa | 37.9 | |
Digging capacity of bucket | KN | 176 | |
Digging capacity of bucket rod | KN | 125 | |
Apperance Size | A Total length | mm | 10220 |
B Total width | mm | 3390 | |
C Total height | mm | 3226 | |
D Width of rotary table | mm | 2830 | |
Working Scope | A Max.digging height | mm | 9595 |
B Max unloading height | mm | 6745 | |
C Max digging depth | mm | 6960 | |
D Max vertical digging bepth | mm | 5545 | |
E Max digging radius | mm | 10240 | |
F Max swing radius | mm | 3850 | |
G Min tail swing radius | mm | 2985 |
Other products:
Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( 54873020, 54798871, 54798867, 54633157, 54622108, 54621778, 54621524, water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
![]() |
CVXE250C Hydraulic Crawler Excavator Road Construction Long Arm 25 ton Excavator Images |
