1,The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
2,The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
3,The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4,The advanced structure and hinge points on the digging end and the industry’s largest rotating angle of the bucket ensure strong soil holding capacity.
Specification:
| | Bucket digging force | kN | 24.6 |
| Hydraulic system | Rated flow of main pump | L/min | 102 |
| | Pressure of prime valve | MPa | 22 |
| | Pressure of pilot system | MPa | 3.9 |
| Oil Capacity | Fuel tank capacity | L | 40 |
| Hydraulic tank capacity | L | 35 |
| Engine oil capacity | L | 6 |
| | Overall length | mm | 4960 |
| Appearance size | Overall width | mm | 1740 |
| | Overall height | mm | 2535 |
| | Width of platform | mm | 1585 |
| | Length of crawler | mm | 2220 |
| | Overall width of chassis | mm | 1740 |
| | Width of crawler | mm | 300 |
| | Track length on ground | mm | 1440 |
| | Crawler gauge | mm | 1721 |
| | Clearance under counterweight | mm | 587 |
| | Min. ground clearance | mm | 297 |
| | Min. tail swing radius | mm | 870 |
| Working scope | Max. digging height | mm | 5215 |
| Max. dumping height | mm | 3760 |
| Max. digging depth | mm | 3060 |
| Max. vertical wall digging depth | mm | 2260 |
| Max. digging reach | mm | 5415 |
| Min. swing radius | mm | 2170 |
| | Boom Length | mm | 2560 |
| Standard Congratulation | Arm Length | mm | 1350 |
| | Bucket Capacity | m³ | 0.11
|
